Specification

Boresize(mm)

20

25

32

40

Acting type

Double acting、Double acting with cushion、Single acting

Fluid

Air(to be filtered by 40μm filter element)

Operating
pressure

Double acting

0.15~1.0MPa(22~145psi)(1.5~10.0bar)

Single acting

0.2~1.0MPa(28~145psi)(2.0~10.0bar)

Proof pressure

1.5MPa(215psi)(15bar)

Temperature ℃

-20~70

Speed range mm/s

Double acting:30~800 Single acting:50~800

Stroke tolerance

0~150+16°>150+1;5

Cushion type

MFC/MFCD/MFCJ Series:Variable cushion;Other series:Bumper

Port size [Note1]

1/8"

1/4"

Series Model

Available Models

MF20 Series

MF20-25,MF20-50,MF20-75,MF20-80,MF20-100,MF20-125,MF20-150,

MF20-160 MF20-175,MF20-200,MF20-250,MF20-300

MF25 Series

MF25-25,MF25-50,MF25-75,MF25-80,MF25-100,MF25-125,MF25-150,MF25-160 MF25-175,

MF25-200,MF25-250,MF25-300,MF25-350,MF25-400,MF25-450,MF25-500

MF32 Series

MF32-25,MF32-50,MF32-75,MF32-80,MF32-100,MF32-125,MF32-150,MF32-160

MF32-175,MF32-200,MF32-250,MF32-300,MF32-350,MF32-400,MF32-450,MF32-500

MF40 Series

MF40-25,MF40-50,MF40-75,MF40-80,MF40-100,MF40-125,MF40-150,MF40-160 MF40-175,

MF40-200,MF40-250,MF40-300,MF40-350,MF40-400,MF40-450,MF40-500
